86 Rev 2.3 • 14 Oct 08
7. Technical Details
Video Specifications
Video Specifications
The following table provides video specifications for the NV5128 Multi-Format Router:
Specification Detail
Video reference input Type: analog video reference.
Standard: PAL, NTSC, or tri-level sync.
Connector: loop-through, BNC.
Impedance: 75 Ω or Hi-Z (greater than 20 kΩ), not selectable.
Input Level: 0.5 Vpp to 2.0Vpp.
Input Return Loss: ≥ 30 dB to 5 MHz.
SD inputs and outputs Type: standard definition, serial digital video.
Standard: SMPTE 259M and 344M.
Data rates: Automatic reclocking at 143, 177, or 270 Mb/s or automatic
bypass.
Data rates: Pass-through at 10 Mb/s to 270 Mb/s.
Connector: BNC.
Impedance: 75 Ω.
Cable equalization: 300 m Belden 1694A, or equivalent cable, at 270 Mb/s.
Router path: non-inverting.
Input and output return loss: > 15 dB, 5 to 270 MHz.
Output level: 800 mVpp ± 10%.
Output rise/fall time: 600 ps ± 10%.
Output overshoot: ≤ 10% of max amplitude.
Output alignment jitter: ≤ 0.2 UIpp from 1.0 kHz to 27 MHz
Output timing jitter: ≤ 0.2 UIpp from 10 Hz to 1.0 kHz
SWB (SD and HD) inputs and
outputs
Type: high definition, serial digital video.
Standard: SMPTE 259M, 344M and 292M.
Data rate: Auto re-clocking at 143, 177, 270, 360, 540 Mb/s and 1.483 and
1.485 Gb/s or auto bypass.
Data rate: pass-through at 10 Mb/s to 1.5 Gb/s.
Connector: BNC.
Impedance: 75 Ω.
Cable equalization: 150 m Belden 1694A, 85 m Belden 1855A, or
equivalent cable, at 1.5 Gb/s.
Router path: non-inverting.
Output level: 800 mVpp ± 10%.
Input and output return loss: > 15 dB, 5 MHz to 1.5 GHz.
Output rise/fall time: ≤ 270 ps.
Output overshoot: ≤ 10% of max amplitude.
Output alignment jitter: ≤ 0.2 UIpp from 100 kHz to 150 MHz.
Output timing jitter: ≤ 1.0 UIpp from 10 Hz to 100 kHz.
