NV5128 Multi-Format Router • User’s Guide 95
A. Part Numbers
Power Supplies
Machine Control and Time Code
This table lists the port cards and associated backplanes for machine control (port) routing and for
switching linear time code signals:
Control Cards
This table lists the control card. One card is required, but two may be installed for redundancy:
**Single controllers should be inserted in slot 1. Redundant (backup) modules should be inserted in
slot 2.
Power Supplies
This table lists the power supplies used in the NV5128 frame. One module is required, but two may
be installed for redundancy:
**Single controllers should be inserted in slot 1. Redundant (backup) modules should be inserted in slot 2.
Part Name or Function Backplane(s) Slots Compatible with...
EM0482 32-port machine control I/O
module, standalone (any two
slots)
EM0483 (RJ-45)
2 each.
2N/A
EM0482
(2 each)
64-port machine control I/O
module, 2 each (Slots 11 and 12
and 13 and 14)
EM0483 (RJ-45)
4 each.
4N/A
EM0408 Time code input module (any
Input Slot)
EM0415 (TP) 1 EM0409 (time code output
module)
EM0409 Time code output module (any
output slot)
EM0416 (TP) 1 EM0408 (time code output
module)
Part Name or Function Backplane(s) Slots
EM0374 Router control card
(control card slots 1, 2, or both)**
N/A 1
Part Name or Function Backplane(s) Slots
PS6000 NV5128 power supply N/A 2 power supply bays, either or both bays
