84 Rev 2.3 • 14 Oct 08
7. Technical Details
Physical Specifications
Physical Specifications
The following table provides physical specifications for the NV5128 Multi-Format Router:
Environmental Specifications
The following table provides environmental specifications for the NV5128 Multi-Format Router.
Specification Details
Dimensions 8RU (13.97 inches, 354.8 mm) high
19.0 inches (482.6 mm) wide
18.0 inches (457.2 mm) deep
Weight 56 lbs (25.5 kg); 182 lbs (82.7 kg) fully loaded.
Mounting EIA 310-C, 19.0 inches (482.6 mm)
Grounding terminal Copper, accepts 14–6 AWG
Modules and slots 8 input cards, 16 signals each,
8 output cards, 16 signals each,
2 control cards (1 primary, 1 optional secondary),
1 fan module,
2 PS6000 power modules (1 required, 1 optional redundant).
Diagnostic Standard: SMPTE 207M, RS-422/RS-232, configurable.
Connectors: 2, DE9
Serial control Standard: SMPTE 207M, RS-422
Connectors: 4, DE9 (2 per control card)
Ethernet 10/100baseT, IEEE 802.3
Protocol: NVISION Ethernet protocol
Connectors: 2, RJ-45
GSC “Node Bus” Standard: proprietary, serial
Connectors: 2, BNC, loop-through, non-terminating pair.
Impedance: 75 Ω
Power supply alarm Connector: Phoenix, 3-pin
Specification Detail
Operating temperature 0 to 40°C.
Relative humidity 0 to 90%, non-condensing.
