94 Rev 2.3 • 14 Oct 08
A. Part Numbers
Cards, Card Sets, and Backplanes
Analog Video and Standard Definition (SD)
The table lists the analog and SD I/O cards and associated backplanes:
SWB (High Definition and Standard Definition Combined)
This table lists all of the SWB I/O cards and associated backplanes:
*EM0465 16-output SWB modules plug into slots already occupied by the 4-slot-wide EM0463 host module.
** Use blank plates to cover the rear of unused slots. This is required to maintain proper air flow through the
frame.
Part Name or Function Backplane(s) Slots Compatible with...
EM0375 Analog video input module EM0377 (BNC) 1 EM0376 (analog video out)
EM0376 Analog video output module EM0378 (BNC) 1 EM0375 (analog video in)
EM0383 SD digital video input module EM0385 (BNC) 1 EM0384 (SD video out)
EM0433 (AVC video out)
EM0384 SD digital video output module EM0386 (BNC) 1 EM0383 (SD video in)
EM0432 (AVC video in)
EM0432 Analog-to-SD video input
module (AVC Video In)
EM0377 (BNC) 1 EM0384 (SD video out)
EM0433 (AVC video out)
EM0433 SD-to-analog video output
module (AVC video out)
EM0378 (BNC) 1 EM0383 (SD video in)
EM0432 (AVC video in)
Part Name or Function Backplane(s) Slots Compatible with...
EM0395 Classic SWB 16×16 digital
video I/O module (Slots 12 &
13)
EM0396 (1 ea.)
EM0424 (1 ea.)
2See Classic SWB
on page 28.
EM0395
(2 each)
Classic SWB 32×32 digital
Video I/O module (Slots 11 &
12 and 13 & 14)
EM0396 (2 ea.)
EM0424 (2 ea.)
4See Classic SWB
on page 28.
EM0466 Standard SWB 16 input digital
video Input module (Input)
EM0396 (1 ea.) 1 EM0463 (SWB, 128×64 Out)
EM0463 Standard SWB digital video
output module, 16 outputs, with
support for an additional 48
outputs.
See Classic SWB
on page 28
and description below for
EM0465.
EM0424 (1 ea.) 4 EM0465 (16 SWB outputs. A
maximum of three EM0465
modules may be used per
EM0463 host.)
EM0465 Standard SWB digital video
output module (16 outputs,
mates with required EM0463
host module. (Required)
EM0424 (1 for
each installed
module.**)
* EM0463 (128×64 SWB output.
A maximum of three EM0465
modules may be used per
EM0463 host.)
