DD_HV_IO
V
V
DD_POR
RESET
(INTERNAL)
pull-up
enabled
RESET
YES
NO
PAD
POWER-UP Application defined Application defined
POWER-DOWN
t
WK_PU
t
WK_PU
(1)
(1)
(1)
1
Actual PAD slopes will depend on external capacitances and VDD_HV_IO supply.
Figure 4. Weak pull-up electrical characteristics definition
Analog input leakage and pull up/down information is located in the ADC input
description section.
8.2
Output pad specifications
The following figure provides the description of output DC electrical characteristics.
I/O pad specification
SPC5746R Microcontroller Data Sheet, Rev. 6, 06/2017
NXP Semiconductors 15
