11 Preparing a measurement
24 / 80 Instruction Manual Corvis® ST (G/72100/XXXX/EN 1019 Rev01)
If you do not work with a PC/laptop/netbook, enter the patient data via
the control panel and manage the data there. You can also initiate the
measurements and view the measuring results there, see sec. 14, page 48.
Component Function Operation
Display (1) Shows program screens
Serves as a touch screen
 Lightly press the desired button
Control knob
(2)
Changes the corresponding
Parameters
Enables the selected parameters
 Turn the knob to the left or right. The selected
parameter is highlighted in blue.
 Press the control knob downwards. The selected
parameter is enabled or disabled.
Joystick (3) Sets the height, distance and di-
rection to the left and right
 Move the joystick forward, back and sideways, turn
it, “Fine Adjustment” page 35.
Joystick but-
ton (4)
Starts the measurement
manually (if the eye-tracking
function is turned off)
 Press the button.
Buttons (5) Enables the adjacent button
field, depending on the associa-
ted screen
 Press the desired button.
