Page #74 background imageLoading...
Page #74 background image
20 Technical Data
68 / 80 Instruction Manual Corvis® ST (G/72100/XXXX/EN 1019 Rev01)
Transport
Measuring head
Power adapter15 V DC
Computer
Use a computer which is in conformity with the DIN EN 60950 standard.
Other information
Ambient temperature range
-40 — +70 °C
Relative humidity, including condensation
10 — 95%
Air pressure range
500 — 1060 hPa
Power supply 15 V DC; 6 A
Max. power consumption 26 W
Mean Well (05150285)
Mains connection 100 - 240 V
Frequency 50/60 Hz
Max. power consumption max. 90 W
Output 15 V DC
Recommended computer
specifications (for optional
software)
Core i5-42000M, 2.5 GHz, 4GB, 500GB,
Windows
7, Intel HD graphics 4600
Dimensions W x D x H 266 x 538 x 495 to525 mm
(10.5 x 21.2 x 19.5- to 20.7 in)
Weight approx. 14 kg (30.8 lbs)
Printer Thermal printer
Display TFT - LCD approx. 150 mm
Contraindications none noted
Lifecycle expectancy up to 10 years
