Chapter 4 Coax/Twinax (CTHI) Emulation
188
PTX Transparent
Lead-in Chars
You can enable additional printer features which are not accessible
through standard TN3270 emulations. To access these features,
send text commands in the data stream. The commands must have
a start and end code. Four sets are available:
• Set 1. start code: <% (default)
stop code: >
• Set 2. start code:¬¬
stop code: $
• Set 3. start code: _%
stop code: _
• User Defined.
Usr Defined HTRN
This option is used to set user defined lead-in characters. The
range is ASCII character. This option allows users to define ther
own lead-in characters for the OKI Specific commands. Select a
hex value for the following codes for the User Defined option:
• Start Code 1 5F (default)
• Start Code 2 5F
• Stop Code 5B
Alt. Set 80-9F
• Printable (default). Prints data in the range of hex 80 through
hex 9F.
• Control Code. Interprets data in the range of hex 80 through
hex 9F as a control code.
