Appendix A Printer Weight And Dimensions
346
Printer Weight And Dimensions
* With a power stacker, the weight increases by 21 lbs. and
the depth increases by 4.75 inches for a deeper rear door.
** With the ZTP option, the weight increases by 12 lbs. and
the height is increased by 7 inches.
Environmental Characteristics
Cabinet Type Dimensions Weight
Height Width Depth Unpacked Packaged
Floor Cabinet 42.5 inches 27 inches 29 inches* 225 lbs. 285 lbs.*
Pedestal 35 inches* 26 inches 21 inches 105 lbs.** 115 lbs.**
Temperature:
Operating: 50° to 104° F (10° to 40° C) up to 5000 feet
(1524 meters) 50° to 90° F (10° to 32° C) up to
8000 feet (2438 meters)
Storage: -40° to 158° F (- 40° to 70° C)
Relative Humidity
Operating: 15% to 80% (noncondensing)
Storage: 15% to 90% (noncondensing)
