Unload Paper
45
Figure 18. Completely Removing the Paper
8. To completely remove the paper from the printer:
a. Raise the platen lever as far as it will go and open both
tractor doors.
CAUTION
Be careful when pulling any paper backward through the
paper path, especially when using a label stock. If you are not
careful, labels can detach and adhere to the printer within the
paper path, where only an authorized service representative
can remove them.
b. Open the cabinet front door.
c. Gently pull the paper down through the paper slot. Allow
the paper to fall into the paper supply area.
d. Remove the paper from the paper supply area.
Platen Lever
Tractors Doors (2)
To Next Page
