Changing Ribbons
49
Figure 21. Threading the Ribbon Around the Ribbon Guide
6. Thread the ribbon around the ribbon guide and along the ribbon
path. Be sure to thread the ribbon between the hammer bank
cover and the ribbon mask.
7. Place the empty spool on the left hub.
8. Press the spool down until it snaps into place.
Ribbon Guide
(Both Sides)
Left Hub
Ribbon Spool
Ribbon Mask
A
A
Hammer
Bank Cover
Ribbon Loading
Instructions For
Future Reference
