Troubleshooting > Regular Maintenance

Replace the Waste Toner Box

When the waste toner box is full, the following message will be displayed. Immediately replace the waste toner box.

"Waste toner box is full."

Open the waste toner box cover.

Remove the Waste Toner Box.

Put used Waste Toner Box into the plastic waste bag.

Remove the new Waste Toner Box.

CAUTION

Do not attempt to incinerate parts which contain toner. Dangerous sparks may cause burns.
