EnForcer™ SCR Service Manual I.B. 1561
31
WIRE CONNECTION CHARTS (3 PHASE SCR CHARGERS)
MODEL B *
208 VOLT INPUT 240 VOLT INPUT 480 VOLT INPUT
WIRE MARKER CONNECTION CONNECTION CONNECTION
D2 F1 TO A1 F1 TO A1 F1 TO A1
D7 F1 TO C5 F1 TO C6 F1 TO C6
D3 F2 TO A5 F2 TO A6 F2 TO A6
D3 F2 TO B1 F2 TO B1 F2 TO B1
D4 F3 TO B5 F3 TO B6 F3 TO B6
D4 F3 TO C1 F3 TO C1 V3 TO C1
A2 A1 TO A4 A1 TO A4 A3 TO A4
A2 A2 TO A5 A3 TO A6 B3 TO B4
A2 B1 TO B4 B1 TO B4 C3 TO C4
A2 B2 TO B5 B3 TO B6 A3 TO A4
A2 C1 TO C4 C1 TO C4 B3 TO B4
AS C2 TO C5 C3 TO C6 C3 TO C4
* Replacement part numbers for chargers with letter codes T, W, X, or Y shall be referred to the charger’s tables with code letter “B”
MODEL J
480 VOLT INPUT 550 VOLT INPUT 600 VOLT INPUT
WIRE MARKER CONNECTION CONNECTION CONNECTION
D2 F1 TO A1 F1 TO A1 F1 TO A1
D7 F1 TO C5 F1 TO C6 F1 TO C6
D3 F2 TO A5 F2 TO A6 F2 TO A6
D3 F2 TO B1 F2 TO B1 F2 TO B1
D4 F3 TO B5 F3 TO B6 F3 TO B6
D4 F3 TO C1 F3 TO C1 F3 TO C1
A2 A2 TO A4* A2 TO A4* A3 TO A4*
A2 B2 TO B4* B2 TO B4* B3 TO B4*
A2 C2 TO C4* C2 TO C4* C3 TO C4*
*INDICATES TWO JUMPERS
