EnForcer™ SCR Service Manual I.B. 1561
51
SUB-ASSEMBLY PANEL WIRING
MODEL B
LOOSE WIRE
MARKER # COLOR CONNECTION
G1 GREEN G1 TO DOOR
WIRE MARKER # 208 V CONNECTIONS 240 V CONNECTIONS 480 V CONNECTIONS
D2 F1 TO A1 F1 TO A1 F1 TO A1
D7 F1 TO C5 F1 TO C6 F1 TO C6
D3 F2 TO A5 F2 TO A6 F2 TO A6
D3 F2 TO B1 F2 TO B1 F2 TO B1
D4 F3 TO B5 F3 TO B6 F3 TO B6
D4 F3 TO C1 F3 TO C1 F3 TO C1
A2 A1 TO A4 A1 TO A4 A3 TO A4
A2 A2 TO A5 A3 TO A6 B3 TO B4
A2 B1 TO B4 B1 TO B4 C3 TO C4
A2 B2 TO B5 B3 TO B6 A3 TO A4
A2 C1 TO C4 C1 TO C4 B3 TO B4
A2 C2 TO C5 C3 TO C6 C3 TO C4
MODEL D
LOOSE WIRE
MARKER # COLOR CONNECTION
G1 GREEN G1 TO DOOR
WIRE MARKER # 220 V CONNECTIONS 380 V CONNECTIONS 440 V CONNECTIONS
D2 F1 TO A1 F1 TO A1 F1 TO A1
D7 F1 TO C6 F1 TO C5 F1 TO C6
D3 F2 TO A6 F2 TO A5 F2 TO A6
D3 F2 TO B1 F2 TO B1 F2 TO B1
D4 F3 TO B6 F3 TO B5 F3 TO B6
D4 F3 TO C1 F3 TO C1 F3 TO C1
A2 A1 TO A4 A2 TO A4 A3 TO A4
A2 A3 TOA6 B2 TO B4 B3 TO B4
A2 B1 TO B4 C2 TO C4 C3 TO C4
A2 B3 TO B6 A2 TO A4 A3 TO A4
A2 C1 TO C4 B2 TO B4 B3 TO B4
A2 C3 TO C6 C2 TO C4 C3 TO C4
