SUB-ASSEMBLY PANEL WIRING (con’t)
MODEL J
LOOSE WIRE
MARKER # COLOR CONNECTION
G1 GREEN G1 TO DOOR
WIRE MARKER # 208 V CONNECTIONS 240 V CONNECTIONS 480 V CONNECTIONS
D2 F1 TO A1 F1 TO A1 F1 TO A1
D7 F1 TO C5 F1 TO C6 F1 TO C6
D3 F2 TO A5 F2 TO A6 F2 TO A6
D3 F2 TO B1 F2 TO B1 F2 TO B1
D4 F3 TO B5 F3 TO B6 F3 TO B6
D4 F3 TO C1 F3 TO C1 F3 TO C1
A2 A2 to A4* A2 TO A4* A3 TO A4*
A2 B2 TO B4* B2 TO B4* B3 TO B4*
A2 C2 TO C4* C2 TO C4* C3 TO C4*
*INDICATES DOUBLE JUMPER
MODEL E
400 V CONNECTIONS
WIRE MARKER # CONNECTIONS
D2 F1 TO A1
D7 F1 TO C6
D3 F2 TO A6
D3 F2 TO B1
D4 F3 TO B6
D4 F3 TO C1
