EnForcer™ SCR Service Manual I.B. 1561
58
ES3
LARGE CABINET
REPLACEMENT PARTS
SCHEMATIC
REPLACEMENT PARTS / FUSE VALUES
CAUTION:
THERE ARE DANGEROUS VOLTAGES WITHIN THE BATTERY CHARGER CABINET.
ONLY QUALIFIED PERSONNEL SHOULD ATTEMPT TO ADJUST OR SERVICE THIS
BATTERY CHARGER.
PRINTED CIRCUIT (CONTROL) BOARD
Charger Model Number PCB Part Number Charger Model Number PCB Part Number
ES3-30-1700YNC X1060-09-ES3-1 ES3-64-1250J X1060-09-ES3-2
COMMON PARTS TO ALL MODELS
Description Part Number
Door X054-99-3-19
Top Panel X057-99-3-23
Back Panel X057-99-3-3
Left Side Panel X057-99-3-13
Right Side Panel X057-99-3-22
Base 013-99-3-3
Cross Member, Heat Sink Mtg. X051-99-3-13
Cross Member, Xfmr Mtg, Front X051-99-3-14
Cross Member, Xfmr Mtg, Back X051-99-3-15
Upright Support X052-99-0-6
Door Latch X044-1-32
Door Latch Rivets 164-8-6
SHUNTS
