EnForcer™ SCR Service Manual I.B. 1561
59
Ampere Hours Value Part Number
0-680 150 X117-99-2
681-1200 300 X117-99-1
1201 & UP 300 X 2 X117-99-1
PARTS / FUSE VALUES FOR ES3-30-1700YNC
Description Part Number
Transformer X127-S30-1700Y
AC Fuses (70A) X014-99-70
DC Fuse (400A) X014-30-7
Shunt (300A) X117-99-1
PARTS / FUSE VALUES FOR ES3-64-1250J
Description Part Number
Transformer X127-S64-1250J
AC Fuse, 480V Connection, 100A X014-99-100
AC Fuse, 550/600V Connection, 90A X014-99-90
DC Fuse (250A) X014-30-4
Shunt (300A) X117-99-1
AC INPUT AND FUSES
Special Models: NOTE: Special charger models might not be listed in these tables. However, AC input is listed on
the charger nameplate. AC Fuse Values are listed on a decal inside the charger. The AC Fuse part number would be:
X014-99-X, where X would equal the AC Fuse Value.
