Olympia Millennium-E - Page 229

Front
Bumper
22cm (d12)
56 cm (d12)
Conduit runs from Front bumper JB
7cm (d12)
2cm (d12)
42cm (d9)
75cm (d9)
9cm (d9)
8cm (d9)
Front bumper harness
Refer to: Main conduit runs for JBs
Horn
R Light
L Light
Pump
Icemaking watertank empty
Icemaking watertank half
Icemaking watertank full
98 - RD/YL
97 - BK
96 - YL
94 - BK
95 - GRN
94 - BK
85 - GRAY
81- PINK
86 - PINK
87 - BRN
88 BK 89 ORNG
86 - PINK
87 - BRN
94 - BK
86 - PINK
87 - BRN
94 - BK
94 - BK
87 - BRN
87 - BRN
86 - PINK
86 - PINK
23920-9313
Use male pins on harness side where applicable
