The Ultimate Ice Resurfacer 54
Install the blade bolts and nger tighten remembering to utilize the row of holes closest to
the cutting edge. The second row of holes should be used when the blade has been ground
down to 4 inch (approx. 10.16 cm) overall width.
The Order is Important
Following the diagrams below, begin to install the blade bolts. Finger tighten the bolts. DO NOT
use lock washers as they will damage the blade holder.
