The Ultimate Ice Resurfacer 56
Wrong Sequence
Please note: Tightening the bolts in any other order, such as from the end to the middle or at
random will result in a warped blade and uneven ice.
The blade holder is feathered by 1/16“ (approx 1,6 mm) over the last 6” to 7" (15.2 to 17.78
cm) at each end. This prevents ridges from forming on the ice.
Removal of the blade is done in reverse order to that in which it was installed!
Blade Holder Tapered 1/16” to 0
Over 6.0” Both ends
6.0
1/16
View A
A
Blade
Blade Holder
1/16" (0.16 cm)
7"
(17.78 cm)
