The Ultimate Ice Resurfacer 71
19. Check the tension on the conditioner chain. There should be between a quarter and
half- inch play (6,5-12,7mm).
20. Check the auger for up and down and side to side movement.
21. Check electrical connection for conditioner (horizontal auger) motor.
22. Check the blade holder pivot bolts to make sure they are tight. Replace the conditioner
cover plate and install the locking pin. Go to the back of the ice resurfacer and ip up
the towel.
23. Check the squeegee making sure it ts tightly from end to end and there are no nicks
or cuts.
24. Examine the bottom side of the towel. Make sure it is clean, debris free and that the
loops of the towel are in good condition.
25. Check the bottom of the runners again for burrs or nicks.
26. If your OLYMPIA is equipped with the optional edger on the conditioner, check the
cutting tips for damage and make sure the plate is securely attached.
27. Check all the hydraulic hose connections on the edger and make sure there are no uid
leaks.
28. Check the electrical connections.
29. Check lug nuts and tire pressure and general condition of tire and studs on left rear wheel.
30. Check the board brush. Make sure that no debris is caught in the brush and that there is
no free play.
31. Move the snow dump tank safety support bars to the stored position and lock in place.
32. Using a three point mount, step onto the ice resurfacer and sit down.
33. Turn the start key to the ON position.
34. Check the horn and the lights.
35. Make sure the conditioner is all the way up by pushing and holding the conditioner UP
switch on the dash.
