The Ultimate Ice Resurfacer 72
36. Test the elevator system. First, make sure the toggle switch is in the FORWARD
position, then push the ON OFF switch for the elevator. While it is still running turn
the toggle switch to the REVERSE position. The augers should come to a stop and then
reverse direction. Then switch back to the forward position and shut o by lifting the
ON OFF switch.
37. While the elevator is running check the snow breaker`s manual override by pushing the
manual override switch down and then up to make sure the snow breaker cycles.
38. If the wash water tank is full turn on the wash water only long enough to make sure
the wash water valve opens and you have an unobstructed water ow on both sides of
the conditioner. Note (The augers must be turned on and the gear selector in the drive
position to perform this check).
39. Check the board brush by pushing the board brush switch down, to lower the board
brush and then up to raise the board brush.
40. Depress the brake pedal to check the brake lights.
41. Check the blade adjustment hand crank wheel. Make sure it turns freely.
42. Visually inspect snow breaker and cylinder to make sure all fasteners are tight.
43. Turn on the tire wash to make sure the pump works.
44. At least once a month lower the conditioner almost to the oor, insert the hand pump
handle into the emergency hand pump located under the seat, push the switch under
the seat to the HAND PUMP position and proceed to pump the conditioner up. After this
is complete be sure to return the switch to the DRIVE position. Remove the hand pump
handle and restow it.
45. Remove all hoses and cables from the ice resurfacer.
46. Complete the log book entry that you have performed the circle check.
47. You have now completed the safety check and are ready to proceed onto the ice
surface and begin the resurfacing process. Make sure you use the horn when crossing
any pedestrian areas.
