22 Nomenclature of respective portions
Interface cable
DP2-AOU
Front
Back
2-1 Hardware
Main switch
LED
LAN cable connector
DC input connector
USB connector
(USB3.1 Gen1)
Display connector
HDMI
Camera head DP2-AOU
RS-232C connector
For connecting control box (U-CBS, etc.) (p. 96)
Microphone input connector
Line output connector
USB connector
(USB3.1 Gen1)
