Olympus DP23-AOU - Functions Linked with Microscope; Application Conditions

DP23-AOU/DP28-AOU
95
By connecting DP23-AOU or DP28-AOU to the control box for microscope or the microscope frame, you can use
functions linked with the microscope described below.
Linked function Explanation
Automatic scale bar
change
When the objective magnification is changed by changing the coded revolving nosepiece
or the motorized revolving nosepiece, the size of the scale bar is changed automatically
according to the magnification changed.
*The objective magnification must be set in advance. For setting procedures, see "Setting
the microscope (p.84)".
Shutter switch By attaching the hand switch for exposure (U-HSEXP) to the microscope frame, you can
acquire images while observing with the microscope.
You can use the linked functions when the following control box or the microscope frame is combined.
· U-CBS
· U-CBM
· BX3-CBM
· BX3-CBH
· BX3M-CB
· BX3M-CBFM
· STM7-CB
· STM7-CBA
· MX63-F
· MX63L-F
· You can also connect the camera to the microscope without connecting the hand switch for exposure U-HSEXP.
In this case, you cannot use the shutter switch function.
· You can also connect the camera to the microscope without connecting the revolving nosepiece with coded
functions. In this case, you cannot use the automatic scale bar change function.
TIP
88 Functions linked with microscope
8-1 Application conditions
