DMTA-20015-01EN [U8778402], Rev. M, February 2017
Basic Operation
91
2. On the right-hand side of the OmniScan MX, lift the rubber seal covering the DC
adaptor connector plug (see Figure 8-1 on page 91).
Figure 8-1 The OmniScan MX DC power adaptor plug
3. Connect the DC power adaptor to the OmniScan MX DC power adaptor plug (see
Figure 8-1 on page 91).
4. Press the Power key to start the OmniScan MX.
8.2.2 Lithium-Ion Batteries
The OmniScan MX holds up to two lithium-ion batteries, but will operate even with
only one battery installed. When two batteries are installed, the OmniScan MX
operates by default using the battery with the highest charge, and automatically
switches to the second battery once the first battery’s remaining charge is less
than 5 %.
