C.1 Acoustic Specifications
This section describes the acoustic specifications for the pulser, receiver, and beam
formation (see Table 34 on page 138).
Table 34 Acoustic specifications — OMNI-M-PA32128
Pulser
Voltage Low: 45 V
High: 90 V
Pulse width Adjustable from 30 ns to 500 ns; resolution
of 2.5 ns.
Fall time <5 ns
Pulse shape Negative square pulse
Output impedance <30 Ω
Receiver
Gain range 0 dB to 74 dB in steps of 0.1 dB, maximum
input signal 1.25 Vp-p
Input impedance 50 Ω
System bandwidth 0.53 MHz to 21 MHz, ±10 % (−3dB)
Beam formation
Scan type Sectorial and linear
Aperture 32 elements
Number of elements 128 elements
Number of focal laws 256
Delay range transmission 0 µs to 10 µs in 2.5 ns increments
Delay range reception 0 µs to 10 µs in 2.5 ns increments
