DMTA-20015-01EN [U8778402], Rev. M, February 2017
Chapter 6
68
Table 13 Pinout for the scanner interface LEMO connector
Pin I/O Signal Description Current Level
1InAINAnalog input ±2.5mA
(2 kΩ
input
impedan
ce)
±5 V
2 Out +5 V External power supply
This power is shared with pin 2
of the serial connector (see
“Serial Connector” on page 66).
500 mA N/A
3 In DIN1 Digital input 1.
Programmable input. Can be
configured for different
functionalities. By default, this
input is disabled. Refer to the
OmniScan MXU Software User’s
Manual (“Configuring the Digital
Input”) for information on
programming this input.
To activate the input, you must
use a high-level signal with a
minimum signal length of 50 ms.
N/A TTL
4 In DIN2 Digital input 2.
Programmable input. Can be
configured for different
functionalities. By default, this
input is disabled. Refer to the
OmniScan MXU Software User’s
Manual (“Configuring the Digital
Input”) for information on
programming this input.
To activate the input, you must
use a high-level signal with a
minimum signal length of 50 ms.
N/A TTL
