DMTA-20015-01EN [U8778402], Rev. M, February 2017
Connector References
69
5 In DIN3 Digital input 3.
Programmable input. Can be
configured for different
functionalities. By default, this
input is disabled. Refer to the
OmniScan MXU Software User’s
Manual (“Configuring the Digital
Input”) for information on
programming this input.
To activate the input, you must
use a high-level signal with a
minimum signal length of 50 ms.
N/A TTL
6 In DIN4 Digital input 4.
Programmable input. Can be
configured for different
functionalities. By default, this
input is disabled. Refer to the
OmniScan MXU Software User’s
Manual (“Configuring the Digital
Input”) for information on
programming this input.
To activate the input, you must
use a high-level signal with a
minimum signal length of 50 ms.
N/A TTL
7OutDOUT1/
PaceOut
Digital out 1/pace output ±15 mA TTL
8 Out DOUT2 Digital output 2 ±15 mA TTL
9InPhA
axis 1
Encoder 1: phase A/clock/up/
down
N/A TTL
10 In PhB
axis 1
Encoder 1: phase B/direction/
N.U./N.U.
a
N/A TTL
11 In PhB
axis 2
Encoder 2: phase B/direction/
N.U./N.U.
N/A TTL
Table 13 Pinout for the scanner interface LEMO connector (continued)
Pin I/O Signal Description Current Level
