Overview of the Equipment
85
Figure 7-3 Right side panel of the OmniScan MX
DC power adaptor plug
Used to connect an external DC power adaptor to the OmniScan MX.
Headphone jack
Used to connect a set of headphones or external speakers to the OmniScan MX for
greater audio capacity than the internal speaker.
Memory card slot
Slot for inserting a CompactFlash memory card.
Battery compartment door
This door provides access to the battery compartment. Battery replacement is
covered in “Battery Removal and Installation” on page 93.
DC power
adaptor plug
Memory card slot
Headphone jack
Battery
compartment
door
