M.5 ECA Acquisition Module Specifications
This section covers the ECA acquisition module specifications, and includes the
general specifications for the module, in addition to the specifications applicable to
the multiplexer and data parameters.
M.5.1 General Specifications
10 −VDC_DRV_P External MUX power supply −8/−10 V 500 mA
11 IN1+ Input 1 positive
12 IN1− Input 1 negative
13 IN2+ Input 2 positive
14 IN2− Input 2 negative
15 IN3+ Input 3 positive
16 IN3− Input 3 negative
17 IN4+ Input 4 positive
18 IN4− Input 4 negative
19 +VDC_DRV_P External MUX power supply +8/+10 V 500 mA
Table 66 General specifications — OMNI-M-ECA4-32
Receptacles 1 Olympus eddy current array probe
receptacle
1 19-pin Fischer eddy current probe
receptacle
1 BNC receptacle
Number of channels 1 to 64
Table 65 Pinout for the 4CH connector [OMNI-M-ECA4-32 module] (continued)
Pin Signal Description Current
