DMTA-20015-01EN [U8778402], Rev. M, February 2017
Specifications
63
Alarms 3 TTL, 5 V, 15 mA maximum
Analog output 2 analog outputs (12-bit resolution) ±5 V
nominal in 10 kΩ, , maximum 10 mA per
output
Pace input 5 V, TTL pace input
a. At this time, OTG is available in host mode only.
Table 11 OmniScan MX2 alarms
Alarms
Number of alarm zones 3
Conditions Any logical combination of gates
Analog outputs 2
Table 10 OmniScan MX2 general specifications (continued)
