DMTA-20015-01EN [U8778402], Rev. M, February 2017
Chapter 5
62
I/O ports
USB ports 2 USB ports compliant with USB 2.0
specifications: OTG
a
(On-the-Go) USB, USB
High Speed (HS)
1 USB port compliant with USB 1.1
specifications: USB full-speed (FS)
USB HS and OTG USB (host mode) can
operate at high speed, full speed, and low
speed
USB FS can operate at full speed and low
speed
Theoretical speed:
HS: 480 Mbps (megabits per second)
FS: 12 Mbps
LS: 1.5 Mbps
Video output Video out (SVGA)
Ethernet 10/100 Mbps
I/O lines
Encoder 2-axis encoder line (quadrature or
clock/direction)
Digital input 4 digital inputs TTL, 5 V
Digital output 4 digital outputs TTL, 5 V, 15 mA maximum
per output
Remote communication Remote communication RS-232: 2 serial
ports using 3-wire RS-232
Acquisition on/off switch Remote acquisition enable TTL, 5 V
Power output line 5 V nominal, 500 mA maximum, shared
between both Serial Out connector and
Scanner connector power output (short-
circuit protected)
Table 10 OmniScan MX2 general specifications (continued)
