DMTA-20015-01EN [U8778402], Rev. M, February 2017
Connector References
65
6. Connector References
Always use equipment and accessories that meet Olympus specifications. Using
incompatible equipment can result in a malfunction, equipment damage, or injury.
This chapter provides a technical description of the OmniScan MX2 instrument
connectors and adaptor below:
• “Serial Connector” on page 66 ( )
• “Scanner Interface Connector” on page 67
• “Alarm and I/O Connector” on page 70
• “Alarm and I/O Connector” on page 70 ( )
The following information is provided for each of these connectors: a brief
description, the manufacturer’s number, the number of the corresponding cable
connector, an illustration, and a table with the signal pinout for the connector.
The following OmniScan MX2 connectors comply with their respective standards:
• SDHC (memory card slot)
• Circular DC power jack, 2.5 mm pin diameter, 15 VDC to 18 VDC (polarity:
)
•USB
• Fast Ethernet (RJ-45)
•VGA
