DMTA-20015-01EN [U8778402], Rev. M, February 2017
Overview of the Equipment
29
1.1.6.2 Acquisition Indicator Light
The acquisition indicator light is located below the Play key ( ). The color of this
light indicates the operating mode of the OmniScan MX2 (see Table 6 on page 29).
The OmniScan MX2 must be turned off before the acquisition module is installed or
removed.
1.1.6.3 Alarm Indicator Lights
There are three alarm indicator lights (numbered 1, 2, and 3) located on the upper
right corner of the OmniScan MX2. These lights only flash one color (red) and indicate
the trigger status of their respective alarms (set within the software).
For more details about the alarm indicator lights, refer to the OmniScan MXU Software
User’s Manual.
Flashing green • The OmniScan MX2 is in sleep mode.
• The OmniScan MX2 is in sleep mode and battery
charging is complete.
Flashing red A critical factor (excessive temperature, very weak
batteries, etc.) requires immediate attention.
Table 6 Acquisition indicator light statuses
Off Oscilloscope mode acquisition
Orange Freeze analysis mode
Table 5 Power indicator light statuses (continued)
