OMNI-M2-UT-2C Module Specifications
199
Rectification RF, full wave, half wave+, half wave−
Filtering 3 low-pass, 6 band-pass, and 3 high-pass
filters (8 low-pass filters when configured
in TOFD)
Video filtering Smoothing (adjusted to the probe frequency
range)
Programmable TCG
Number of points 32: One TCG (time-corrected gain) curve
per focal law
Range 100 dB per step of 0.1 dB
Maximum slope 40 dB/10 ns
Storage
A-scan recording 6000 A-scans per second (512-point, 8-bit
A-scan).
C-scan recording I, A, B, up to 10 kHz
Maximum file size Limited to available internal flash memory:
300 MB
Table 75 Data specifications — OMNI-M2-UT-2C (continued)
