Omega DP41-B Series - Write to Single Register Command (06)

M - 9
 NOTE: Following bits patterns is the format for 3 bytes data registers of
READING SCALE (“RdG.SC”), INPUT SCALE (“INP.SC”), AND
OUTPUT SCALE (“Out.SC”) which are determined differently than the
above example.
Value
Format
VALUES OF REGISTERS
(3 Hex. Bytes)
Hex.
Pattern
00
hh
(2 hex.characters)
hh
(2 hex.characters)
hh
(2 hex.characters)
Binary bits
pattern
N/A
XXXX
(binary
bits)
XXXX
(binary bits)
XXXX XXXX
(binary bits)
XXXX XXXX
(binary bits)
X XXX
Decimal N/A
DECIMAL
POINT
SIGN
Absolute
Value
Absolute Value Absolute Value
Table 8.2 : Format of 3 bytes Data Value Description of all type of Scale Function.
For detail description of How to determine Sign (+ or -), Decimal Point Position and
absolute value, refer to Section 10.34 and Table 10.28 of Communication Manual.
8.2. Write to Single Register (06)
The following command will write a parameter to the single register.
Send / Response Command string format:
DATA
DEVICE
ADDRESS
FUNCTION
CODE
06
REGISTER
DATA
VALUE
CRC
1 BYTE
hh
1BYTE
06
HB
00
LB
hh
HB
00
LB
hh
LB
hh
HB
hh
