CPC 100 V 3.20
Quick - 2
Quick
Sync w/ V1 AC
Note: Sync w/ V1 AC is not available in all output modes.
A trigger is the occurrence of a selected event, for example, a binary trigger is the first change
of the state at the binary input.
Note that some of the trigger events offered in the Trigger on: combo box depend on the
measured quantity settings below (trigger on measurement).
Trigger on “Overload”: the occurrence or the clearing of an output overload condition (clearing
is delayed by 100 ms to debounce).
Set Sync w/ V1 AC by pressing the menu key that appears when the focus is on
the frequency / phase angle data entry field.
This synchronizes the CPC 100 output frequency with the V1 AC input frequency
(we recommend a minimum input voltage of 10 V on V1 AC, possible range 48 -
62 Hz). In this case the phase angle of the output is displayed rather than the
frequency. Set the phase angle value relative to the phase angle of the V1 AC
input signal.
The icon next to the frequency / phase angle data entry field reflects the actual
setting.
Due to the PLL (phase locked loop) technology, the synchronization with V1 AC
takes places about 100 ms after the test was started.
Select the trigger event
Indicates the signal
condition at the binary
input Bin In.
Threshold value for trigger
on measurements.
Delay time display
The delay time is the time between the last
change of the CPC 100 output value and the
occurrence of the trigger event.
Select to switch off the CPC 100 outputs when
the trigger event occurs.
Clear to leave the CPC 100 outputs on after the
trigger event occurred.
The measurement values are “frozen”.
To store the results, press .
