Common Functions - 1
The test assessment is a manual procedure carried out by the user.
The example below shows an assessment made at a VTRatio test card. However, the
assessment procedure is carried out in the same fashion on all test cards.
► After the test, set the focus on the assessment symbol by turning the handwheel.
► Use the context-dependent menu keys to assess the test.
The String Editor is used to name or rename test cards, tests and templates as well as to fill out
the Comment card.
Any time such an operation becomes necessary, the String Editor starts automatically.
The number of available characters to choose from depends on the String Editor’s use. If, for
example, a user-defined comment is to be entered in the Comment card, the number of
available characters is bigger than if a test is to be renamed. This difference are special
characters, such as !, ?, _, [ ], etc.
Important special characters
Complete the following steps to change the default name, and to enter a name of your choice:
Test not assessed.
Test OK
Test failed
Assessment symbol
Text field
Available
characters
Template phrases
Move right
Change case
Switch between
form and text editor
Move left
Finish editing
Abort editing,
discard changes
carriage return (line feed)
tab (special function in Form Editor mode; refer to page Others-7).
► Delete the default name by repeatedly pressing the backspace key.
► Enter the new test or folder name by consecutively selecting the characters of
your choice from the “on-screen keyboard” with the Up / Down keys or by
navigating to it with the handwheel.
► Acknowledge every selected character by pressing the handwheel or Enter.
Test Assessment
Common Functions
