Omicron CPC 100 User Manual

CPC 100 V 3.20
Resistance - 1
The Resistance test card provides a total of three output ranges. The test setup depends on
the selected range.
1µ to 10 m
Setup for a µ measurement in the 400 A DC range:
Inject current from the 400A DC output to both sides of the test object. Input VDC measures the
voltage drop, the software calculates the test object’s resistance.
10 m to 10 
Setup for a m measurement in the 6 A DC range:
Inject current from the 6A DC output to both sides of the test object. To measure this current,
route it via the I AC/DC input as shown in the figure above. Input VDC measures the voltage
drop, the software calculates the test object’s resistance.
10  to 20 k
Setup for an  to kmeasurement in the V DC (2 wire) range:
At this range, the DC input VDC outputs the current needed to measure the resistance.
DANGER
Death or severe injury caused by high voltage or current
► Do not measure on a large inductance in this mode.
► Use RWinding instead.
µ Measurement
Resistance
