Weight and Dimensions
Notes regarding the CP CB2
1. With a mains voltage of 230 V using a 2 x 0.6 m high-current cable at an ambient
temperature of 23 °C ± 5 ° (73 °F ± 10 °F)
2. Signals below 50 Hz or above 60 Hz with reduced values possible
Note: Make sure to establish series or parallel connection, depending on the selected range on
the test card.
Current outputs
Range Amplitude
t
max
1
V
max
2
Power
max
2
f
1000 A AC 0…1000A 25s 4.90V 4900VA 15…400Hz
0 … 500 A 30 min 5.00 V 2500 VA 15 … 400 Hz
2000 A AC 0…2000A 25s 2.45V 4900VA 15…400Hz
Internal measurement of outputs
Output
Guaranteed accuracy Typical accuracy
Amplitude Phase Amplitude Phase
Reading
error
Full
scale
error
Full
scale
error
Reading
error
Full
scale
error
Full
scale
error
2000 A AC
0.25 % 0.25 % 0.50° 0.13 % 0.13 % 0.25°
1000 A AC
0.25 % 0.25 % 0.50° 0.13 % 0.13 % 0.25°
Weight Dimensions (W x H x D)
CP CB2 test set 16 kg (35.3 lbs) 186 x 166 x 220 mm (7.3 x 6.5 x 8.7”),
without handle.
test set & case 25 kg (55.1 lbs) 700 x 450 x 360 mm (27.6 x 17.7 x
14.2”)
DANGER
Death or severe injury caused by high voltage or current
► Do not touch the CPC 100’s outputs and do not touch or unplug any cables while
working with the CP CB2.
