Omicron CPC 100 User Manual

CPC 100 V 3.20
Others: Comment - 7
The Comment card is inserted to a test procedure in the same manner like a test card. Its
purpose is to hold a user-defined comment and / or note regarding the actual test procedure or
other important information, such as operational data of a transformer, for example.
When used for the Comment card, the String Editor differentiates between the input modes
"Form Editor" and "Text Editor". After pressing Edit, "Text Editor" is active. With the exception
of the context-sensitive key to switch between these two modes, the user interface is identical.
To create "flowing" text with no tabs in it, either input mode can be used. Compose a text of your
choice by selecting the individual characters and symbols needed one by one and confirm them
by pressing the handwheel. When finished, acknowledge with OK.
To create such a "2 columns" layout use the Form Editor.
Enter the first word "Substation" and then a tab. Proceed with "Buers" and a carriage return.
Proceed accordingy:
The tab quasi denotes a column-break.
The difference between Form Editor and Text Editor is that text left of the tab (the "first column",
so to speak) cannot be accessed anymore in Text Editor, i.e., it is protected. To add, edit or
delete first column entries use the Form Editor.
How to change a comment
If you need to change an existing comment, press Edit. This starts the String Editor.
Start the appropriate input mode, "Form Editor" or "Text Editor", change the entries of your
choice and press OK.
How to clear a comment
Press Clear Comment. The context-dependent menu keys change and provide two more keys:
Clear All and Clear Text.
Press the context-dependent menu key Edit to start the String Editor, the tool for
entering text.
This is a user-defined comment and/or
note regarding the actual test procedure.
Sub.: Buers
Trans.: TR24
Manuf.: Siemens
Type: KFRM 1863A / 22E
Year: 1955
Se. No.: T-54953
Power: 100 MVA
VecGr.: YN/yn0
Uprim: 220.000 V
Iprim: 262.5 A
Usec: 110.000 V
Isec: 525.0 A
Uk: 10.2 %
Sub. Buers
Trans. TR24
Manuf. Siemens
Type a.s.o.
Clear All: Deletes the entire comment at once, i.e. all text in all columns.
Clear Text: Deletes all to the right of the tab, i.e. everything but the left-hand side column.
Starting the String Editor Form Editor - Text Editor
Others: Comment
