Omicron CPC 100 User Manual

CP TD1
CP TD1 - 8
CP TD1
High-Voltage Output
Conditions: Signals below 45 Hz with reduced values possible. Capacitive linear loads.
Measurements
Test frequencies
TanDelta test card: Column “Hz” of the results table
Special displays in the frequency column “Hz” and their meanings:
Filter for selective measurements
Conditions: f0 = 15 … 400 Hz
Test current (RMS, selective)
a
) IN A (red) or IN B (blue), depending on the mode.
Test voltage (RMS, selective)
Capacitance Cp (equivalent parallel circuit)
Dissipation factor DF (tan)
Power factor PF (cos)
a
) Reduced accuracy of DF and PF at mains frequency or its harmonics. Mains frequency suppression
available by precisely selecting a mains frequency of *50 Hz or *60 Hz in the “Hz” column.
Terminal U / f THD I S t
max
High-voltage
output
10 … 12 kV AC
15 … 400 Hz
< 2 % 300 mA 3600 VA > 2 min
100mA 1200VA >60min
Range Resolution Typical accuracy
15 … 400 Hz 0.01 Hz error < 0.005 % of reading
*50 Hz (*60 Hz) Measurement mode suppressing the mains frequency
interferences; doubles the measurement time.
!30 Hz The selected test voltage is not available in Automatic
measurement (applies to frequencies below 45 Hz only).
?xx Hz Results with reduced accuracy, e.g., in case of a low testing
voltage, influences of partial discharge etc.
Filter bandwidth Meas. time Stop band specification (attenuation)
f0 ± 5 Hz 2.2 s > 110 dB at fx = f0 ± (5 Hz or more)
f0 ± 10 Hz 1.2 s > 110 dB at fx = f0 ± (10 Hz or more)
f0 ± 20 Hz 0.9 s > 110 dB at fx = f0 ± (20 Hz or more)
Terminal Range Resolution Typical accuracy Conditions
IN A or IN B
a
0 …5A AC 5 digits error < 0.3 % of reading +
100 nA
Ix < 8 mA
error < 0.5 % of reading Ix > 8 mA
Range Resolution Typical accuracy
0 … 12000V AC 1 V error < 0.3 % of reading + 1 V
Range Resolution Typical accuracy Conditions
1pF…3F 6 digits
error < 0.05 % of
reading + 0.1 pF
Ix < 8 mA,
Vtest = 300V…10kV
error < 0.2 % of reading Ix > 8 mA,
Vtest = 300V…10kV
Range Resolution Typical accuracy Conditions
0…10%
(capacitive)
5 digits error < 0.1 % of reading
+ 0.005 %
a
f = 45 … 70 Hz,
I<8mA,
Vtest = 300V…10kV
0 … 100
(0 … 10000 %)
5 digits error < 0.5 % of reading
+ 0.02 %
Vtest = 300V…10kV
Range Resolution Typical accuracy Conditions
0…10%
(capacitive)
5 digits error < 0.1 % of reading
+ 0.005 %
a
f = 45 … 70 Hz,
I<8mA,
Vtest = 300V…10kV
0 … 100 % 5 digits error < 0.5 % of reading
+ 0.02 %
Vtest = 300V…10kV
Technical Data of the CP TD1 in Combination with the CPC 100
