Omicron CPC 100 User Manual

CP TD1
CP TD1 - 9
Phase angle 
Impedance Z
Inductance Lx (equivalent serial circuit)
Quality factor QF
Power P, Q, S (selective)
Mechanical Data
Environmental conditions
Weight and dimensions
a
) Case = robust case, IP22
Range Resolution Typical accuracy Conditions
-90 ° … +90 ° 4 digits error < 0.01° Vtest = 300 V … 10 kV
Range Resolution Typical accuracy Conditions
1k … 1200M 6 digits error < 0.5 % of reading Vtest = 300 V … 10 kV
Range Resolution Typical accuracy
1 H … 1000 kH 6 digits error < 0.3 % of reading
Range Resolution Typical accuracy
0 … 1000 5 digits error < 0.5 % of reading + 0.2 %
> 1000 5 digits error < 5 % of reading
Range Resolution Typical accuracy
0 … 3.6 kW 6 digits error < 0.5 % of reading + 1 mW
0 … 3.6 kvar 6 digits error < 0.5 % of reading + 1 mvar
0 … 3.6 kVA 5 digits error < 0.5 % of reading + 1 mVA
Operating temperature -10 ° … +55 °C (+14 … +131 F)
Transport and storage
temperature
-20 ° … +70 °C (-4 … +158 F)
Humidity range 5 … 95 % relative humidity, no condensation
Shock IEC68-2-27 (operating), 15 g/11 ms, half-sinusoid
Vibration IEC68-2-6 (operating), 10 … 150 Hz, acceleration 2 g
continuous (20 m/s²); 5 cycles per axis
EMC EN 50081-2, EN 55011, EN 61000-3-2, FCC Subpart B of Part
15 Class A, EN 50082-2, IEC 61000-4-2/3/4/8, CE conform
(89/336/EEC)
Safety EN 61010-1, EN 60950, IEC 61010-1, produced and tested in
an EN ISO 9001 certified company.
Prepared for IEEE 510, EN 50191, VDE 104
Weight Dimensions (W x H x D)
CP TD1 test set 25 kg
(55.2 lbs)
450 x 330 x 220 mm
(17.7 x 13 x 8.7”)
without handles
test set & case
a
38.1 kg
(84 lbs)
700 x 500 x 420 mm
(27.5 x 19.7 x 16.5”)
CP CAL1 test set 8.8 kg
(19.4 lbs)
450 x 330 x 220 mm
(17.7 x 13 x 8.7”)
without handles
test set & case
a
21 kg
(46.3 lbs)
700 x 500 x 420 mm
(27.5 x 19.7 x 16.5”)
Cables and
accessories
equipment 16.6 kg
(36.6 lbs)
equipment and
case
a
26.6 kg
(58.7 lbs)
680 x 450 x 420 mm
(26.8 x 17.7 x 16.5”)
Equipment trolley equipment 14.5 kg
(32 lbs)
equipment & carton 18.9 kg
(41.7 lbs)
590 x 750 x 370 mm
(23.2 x 29.2 x 14.6”)
CP TD1, CPC 100,
equipment & trolley
(without CP CAL1)
equipment 85 kg
(187.5 lbs)
750 x 1050 x 600 mm
(29.5 x 41.3 x 23.6”)
equipment & packing 125 kg
(275.8 lbs)
Technical Data of the CP TD1 in Combination with the CPC 100
