Omicron CPC 100 User Manual

CPC 100 V 3.20
CPC 100 Technical Data - 1
Note: For detailed information refer to the section “Technical Data” in the CPC 100 Reference
Manual available in pdf format on the CPC 100 Toolsets or the CPC 100 Start Page.
The output is either voltage or current, and is automatically selected by the software or manually
by the user. Current and voltage outputs are overload and short-circuit proof and protected
against over-temperature.
Output transient characteristics
Note: For the individual notes, see “Notes Related to Inputs and Outputs” below.
Range Amplitude
t
max
1
V
max
2
Power
max
2
f
800A AC
3
0 …800A 25s 6.0V 4800VA 15…400Hz
0 … 400 A 8 min 6.4 V 2560 VA 15 … 400 Hz
0 …200A >2h 6.5V 1300VA 15…400Hz
6A AC
10
0 … 6 A > 2 h 55 V 330 VA 15 … 400 Hz
3A AC
10
0 … 3 A > 2 h 110 V 330 VA 15 … 400 Hz
400A DC
0 … 400 A 2 min 6.5 V 2600 VA DC
0 … 300 A 3 min 6.5 V 1950 VA DC
0 …200A >2h 6.5V 1300VA DC
6A DC
4, 10
0 …6A >2h 60V 360VA DC
2000A AC
3
with an optional current booster. For more details, refer to page CP CB2-1.
Range
Amplitude
5
t
max
I
max
Power
max
5
f
2kV AC
3
0…2kV 1min 1.25A 2500VA 15…400Hz
0…2kV >2h 0.5A 1000VA 15…400Hz
1kV AC
3
0…1kV 1min 2.5A 2500VA 15…400Hz
0…1kV >2h 1.0A 1000VA 15…400Hz
500V AC
3
0…500V 1min 5.0A 2500VA 15…400Hz
0…500V >2h 2.0A 1000VA 15…400Hz
130V AC
10
0 … 130 V > 2 h 3.0 A 390 VA 15 … 400 Hz
Changes from “off” or a low
magnitude to a higher magnitude
Changes from a high magnitude to
a lower magnitude or “off”
AC current within one period 300 ms maximum; accordingly less
for smaller magnitudes
AC voltage 1200 ms maximum; accordingly less
for smaller magnitudes
300 ms maximum; accordingly less
for smaller magnitudes
Output Range
Guaranteed accuracy
Typical accuracy
6
Amplitude Phase Amplitude Phase
Reading
error
Full
scale
error
Full
scale
error
Reading
error
Full
scale
error
Full
scale
error
800A AC - 0.20 % 0.20 % 0.20° 0.10 % 0.10 % 0.10°
400A DC - 0.40 % 0.10 % - 0.20 % 0.05 % -
2kV AC
2000 V 0.10 % 0.10 % 0.20° 0.05 % 0.05 % 0.10°
1000 V 0.10 % 0.10 % 0.30° 0.05 % 0.05 % 0.15°
500 V 0.10 % 0.10 % 0.40° 0.05 % 0.05 % 0.20°
5 A 0.40 % 0.10 % 0.20° 0.20 % 0.05 % 0.10°
500 mA 0.10 % 0.10 % 0.20° 0.05 % 0.05 % 0.10°
Generator / Output Section - Current Outputs Generator / Output Section - Voltage Outputs Internal Measurement of Outputs
CPC 100 Technical Data
