CPC 100 Technical Data - 4

CPC 100

Technical Data

Weight and Dimensions

Weight 29 kg (64 lbs), case without protection cover

Dimensions W x H x D: 468 x 394 x 233 mm (18.4 x 15.5 x 9.2"), cover,

without handles.
