Pulse Outputs Section 5-3
Combinations of
Pulse Control
Instructions
The following tables show when a second pulse control instruction can be
started if a pulse control operation is already being executed.
Generally, a second independent-mode positioning instruction can be started
if an independent-mode positioning instruction is being execute, and a second
continuous-mode speed control instruction can be started if a continuous-
mode speed control instruction is being executed. Operation cannot be
switched between the independent and continuous modes, although
PLS2(887) can be started while ACC(888) (continuous mode) is being exe-
cuted.
It is possible to start another operation during acceleration/deceleration and
start another positioning instruction during positioning.
Note (1) SPED(885) (Independent) to SPED(885) (Independent)
• The number of pulses cannot be changed.
• The frequency can be changed.
• The output mode and direction cannot be switched.
(2) SPED(885) (Continuous) to SPED(885) (Continuous)
• The frequency can be changed.
• The output mode and direction cannot be switched.
(3) SPED(885) (Independent) to ACC(888) (Independent)
• The number of pulses cannot be changed.
• The frequency can be changed.
• The acceleration/deceleration rate can be changed.
• The output mode and direction cannot be switched.
(4) ACC(888) (Independent) to ACC(888) (Independent)
or PLS2(887) to ACC(888) (Independent)
• The number of pulses cannot be changed.
• The frequency can be changed.
• The acceleration/deceleration rate can be changed. (The rate can
even be changed during acceleration or deceleration.)
• The output mode and direction cannot be switched.
(5) SPED(885) (Continuous) to ACC(888) (Continuous)
or ACC(888) (Continuous) to ACC(888) (Continuous)
Instruction being
executed
Starting instruction
(❍: Can be executed., ×: Instruction Error occurs and Error Flag goes ON)
INI(880) SPED(885)
(Independent)
SPED(885)
(Continuous)
ACC(888)
(Independent)
ACC(888)
(Continuous)
PLS2(887) ORG(889)
SPED(885) (Independent)
❍❍ (note 1) × ❍ (note 3) ×××
SPED(885) (Continuous)
❍ × ❍ (note 2) × ❍ (note 5) ××
ACC(888)
(Independent)
Steady speed
❍ ××❍ (note 4) × ❍ (note 6) ×
Accelerating or
decelerating
❍ ××❍ (note 4) × ❍ (note 6) ×
ACC(888)
(Continuous)
Steady speed
❍ ×××❍ (note 5) ❍ (note 7) ×
Accelerating or
decelerating
❍ ×××❍ (note 5) ❍ (note 7) ×
PLS2(887) Steady speed
❍ ××❍ (note 4) × ❍ (note 8) ×
Accelerating or
decelerating
❍ ××❍ (note 4) × ❍ (note 8) ×
ORG(889) Steady speed
❍ ××××××
Accelerating or
decelerating
❍ ××××××
