Omron CP1H CPU User Manual

311
Pulse Outputs Section 5-3
PLS2(887) Settings to Move from Position A to Position C
PLS2(887) Settings to Move from Position A to Position D
Y axis Acceleration rate: 2,000 Hz/4 ms D40 #07D0
Deceleration rate: 2,000 Hz/4 ms D41 #07D0
Target frequency: 100,000 Hz D42 #86A0
D43 #0001
Number of output pulses: 50,000 pulses D44 #C350
D45 #0000
Setting details Address Data
Setting details Address Data
X axis Acceleration rate: 2,000 Hz/4 ms D50 #07D0
Deceleration rate: 2,000 Hz/4 ms D51 #07D0
Target frequency: 100,000 Hz D52 #86A0
D53 #0001
Number of output pulses: 35,000 pulses D54 #88B8
D55 #0000
Y axis Acceleration rate: 2,000 Hz/4 ms D60 #07D0
Deceleration rate: 2,000 Hz/4 ms D61 #07D0
Target frequency: 100,000 Hz D62 #86A0
D63 #0001
Number of output pulses: 50,000 pulses D64 #C350
D65 #0000
Setting details Address Data
X axis Acceleration rate: 2,000 Hz/4 ms D70 #07D0
Deceleration rate: 2,000 Hz/4 ms D71 #07D0
Target frequency: 100,000 Hz D72 #86A0
D73 #0001
Number of output pulses: 25,000 pulses D74 #61A8
D75 #0000
Y axis Acceleration rate: 2,000 Hz/4 ms D80 #07D0
Deceleration rate: 2,000 Hz/4 ms D81 #07D0
Target frequency: 100,000 Hz D82 #86A0
D83 #0001
Number of output pulses: 30,000 pulses D84 #7530
D85 #0000
