483
LCD Option Board Function Section 8-6
6. Press the OK button to start loading.
A rate of loading will be displayed in the screen.
7. When the rate comes up to 0%, the loading is finished. Then it will display
a complete screen.
Saving Data from PLC to Memory Cassette
Example Save data from the PLC to Memory Cassette.
1,2,3...
1. Switch to the Setup Mode.
2. Press the Down button to select MC.
3. Press the OK button to enter the Memory Cassette menu.
4. Press the Down button to select PLC->MC.
5. Press the [OK] button to enter the "PLC->MC" menu.
Select the saving mode in the following table.
Saving Mode Meaning
Autoboot PRG If the power turns ON, the operation cannot be
executed.
Autoboot RUN Even if the power turns ON, the operation can be
executed.
To Next Page
