Omron CP1H CPU User Manual

555
Trouble Shooting Section 9-11
010E --- No routing table entry (send
failed)
Commands
Bit 15: OFF
Bits 08 to 14: SNA
Bits 00 to 07: SA1
Responses
Bit 15: ON
Bits 08 to 14: DNA
Bits 00 to 07: DA1
Set the local node, remote
node, and relay nodes in
the routing tables.
---
010F --- Routing table error (send
failed)
Create the routing tables
correctly.
---
0110 --- Too many relay points (send
failed)
Reconstruct the network
or correct the routing
tables so that commands
are sent to within a 3- level
network range.
---
0111 --- Command too long (send
failed)
Check the command for-
mat and set the correct
command data.
---
0112 --- Header error (send failed) Check the command for-
mat and set the correct
command data.
---
0117 --- Internal buffers full; packet
discarded
Change the network so
that traffic is not concen-
trated.
---
0120 --- Unexpected routing error Check the routing tables. ---
0123 --- Internal send buffers full;
packet discarded
Change the network so
that traffic is not concen-
trated.
---
0125 --- Time out error Resend the command. ---
021A FLASH Logic error in setting table 00 02: Network
parameters
03: Routing
tables
04: Unit
Setup
05: CPU Bus
Unit Words
(CIO/DM)
Recreate the data speci-
fied by the 2nd byte of the
detailed error code.
Saved
03C0 FLASH FINS/TCP setting error 01 to 02:
Connection
No.
01:
Automatically
allocated
FINS node
address
duplication
02:
Destination
IP address
error
03:
Destination
port number
error
Set the FINS/TCP
settings correctly.
---
03C2 --- FINS/TCP packet
discarded
01 to 02:
Connection
No.
03:
Reception
error
04:
Transmission
error
Resend the command. ---
There is too much load
(traffic) on the Ethernet
Option Board. Correct the
system so that traffic is not
concentrated.
---
Error
code
ERR
LED
Meaning
Detailed error code
Correction EEPROM
1st byte 2nd byte
