Auxiliary Area Allocations by Address Appendix D
A322
and
A323
All Pulse Output
2 PV
Contain the number of pulses output
from the corresponding pulse output
port.
PV range: 80000000 to 7FFFFFFF
hex
(-2,147,483,648 to 2,147,483,647)
When pulses are being output in the
CW direction, the PV is incremented
by 1 for each pulse.
When pulses are being output in the
CCW direction, the PV is decre-
mented by 1 for each pulse.
PV after overflow: 7FFFFFFF hex
PV after underflow: 80000000 hex
A323 contains the leftmost 4 digits
and A322 contains the rightmost 4
digits of the pulse output 2 PV.
A325 contains the leftmost 4 digits
and A324 contains the rightmost 4
digits of the pulse output 3 PV.
Cleared when operation starts.
Note If the coordinate system is
relative coordinates (unde-
fined origin), the PV will be
cleared to 0 when a pulse
output starts, i.e. when a
pulse output instruction
(SPED(885), ACC(888), or
PLS2(887)) is executed.
--- --- Cleared Refreshed
each cycle
during
oversee
process.
Refreshed
when the
INI(880)
instruction
is exe-
cuted (PV
change).
---
A324
and
A325
All Pulse Output
3 PV
Cleared ---
A326 A326.00 Pulse Output
2 Accel/Decel
Flag
This flag will be ON when pulses are
being output from pulse output 2
according to an ACC(888) or
PLS2(887) instruction and the output
frequency is being changed in steps
(accelerating or decelerating).
Cleared when operation starts or
stops.
OFF: Constant speed
ON: Accelerating or decelerating
--- --- Cleared Refreshed
each cycle
during
oversee
process.
---
A326.01 Pulse Output
2
Overflow/
Underflow
Flag
This flag indicates when an overflow
or underflow has occurred in the
pulse output 2 PV.
Cleared when operation starts.
OFF: Normal
ON: Overflow or underflow
--- --- Cleared Cleared
when the
PV is
changed
by the
INI(880)
instruction.
Refreshed
when an
overflow or
underflow
occurs.
---
A326.02 Pulse Output
2 Output
Amount Set
Flag
ON when the number of output
pulses for pulse output 2 has been
set with the PULS(886) instruction.
Cleared when operation starts or
stops.
OFF: No setting
ON: Setting made
--- --- Cleared Refreshed
when the
PULS(886)
instruction
is exe-
cuted.
Refreshed
when pulse
output
stops.
---
A326.03 Pulse Output
2 Output
Completed
Flag
ON when the number of output
pulses set with the PULS(886) or
PLS2(887) instruction has been out-
put through pulse output 2.
Cleared when operation starts or
stops.
OFF: Output not completed.
ON: Output completed.
--- --- Cleared Refreshed
at the start
or comple-
tion of
pulse out-
put in inde-
pendent
mode.
---
Address Name Function Settings Status
after
mode
change
Status
at star-
tup
Write
timing
Related
flags, set-
tings
Words Bits
